Matek ASPD-4525 Digital AirSpeed Sensor
Specifications
- Board Supply voltage: 4~5.5V DC
- Sensor: MS4525DO
- Working current: 5mA
- Output: I2C (SCL & SDA)
- Pressure Ranges: 1 PSI (6.89kPa)
- Maximum Pressure: 20 PSI (137.9kPa)
- Operating Temperature: -40°C ~ 125°C
- Accuracy: ±0.25% SPAN
- Red LED: power indicator
- JST-GH sequence: 5V, SCL, SDA, GND
- Weight: 3.5g (sensor board)
Including
- 1x ASPD-4525 Sensor Board.
- 1x JST-GH-4P to JST-GH-4P 20cm silicon wire
- Pitot Tube.
- Clear silicon tubing 40cm
Wiring
- 5V to FC 4~5.5V
- SCL to FC I2C_SCL
- SDA to FC I2C_SDA
- G to FC GND
Tips
There is known Airspeed sensor issue with INAV3.0.0 & 3.0.1
Pls use other INAV fw version. e.g. 3.0.2 or 4.0.x
