GEPRC Mark5 O4 Pro DC Frame Kit GEP-MK5
The GEPRC MARK5 O4 Pro frame is designed specifically for the DJI O4 Air Unit Pro.
It features a redesigned camera mount and custom shock-absorbing silicone, improving compatibility and vibration resistance for a more stable flight experience.
Features
- Optimized for DJI O4 Air Unit Pro, offering enhanced compatibility.
- DC and wide X shapes, fit for a variety of flying situations.
- Two TPU camera mounts, compatible with all action cameras.
- Quick-release arms with just two screws for easy swapping.
- 3K carbon fiber frame that is lighter, stronger, and more durable.
DC Specifications
- Model: GEP-MK5 O4 Pro DC Frame
- Wheelbase: 230mm
- Weight: 197.0g ± 10g
- Color: emerald green / coral orange
- Top Plate Thickness: 2.5mm
- Arm Thickness: 5.0mm
- Bottom Plate Thickness: 2.5mm
- FC Mounting Pattern: 30.5mm * 30.5mm
- VTX Mounting Pattern: 20mm * 20mm / 25.5mm * 25.5mm / 30.5mm * 30.5mm
- Motor Mounting Pattern: 16mm * 16mm / 19mm * 19mm
- Camera Mounting Pattern: 20mm
- Recommended Prop：5-inch
Includes
- 1 x GEP-MK5 O4 Pro Frame
- 1 x 15*250mm heavy-duty Velcro straps
- 2 x Battery anti-slip pads
- 1 x 3D printouts pack
- 2 x 20*250mm rubber anti-slip straps
- 1 x L-shaped screwdriver 1.5mm
- 1 x L-shaped screwdriver 2mm
- 1 x L-shaped screwdriver 3mm
- 1 x M8 wench
- 1 x Screw pack
